Applications:AGV obstacle avoidance systems, intelligent high-bay warehouses, position and distance detection, Water level measurement in sewage and rainwater wells, crane positioning, port hoisting, Garbage bin fill-level monitoring, water conveyance tunnel water level monitoring
Measuring Range:0.25~3.5m
| Technical Parameters | |
|---|---|
| Detection Range | 0.25~3.5 m |
| Blind Zone | 0.25 m |
| Transducer Frequency | 64kHz±5% |
| Response Delay | ≤300 ms |
| Operating Voltage | 24V±10% |
| Protection Circuit | Reverse Polarity Protection, Transient Overvoltage Protection |
| No-Load Current | ≤25 mA |
| Output | |
| Output Mode | 1 SPST (Single-Pole Single-Throw) Relay |
| Communication Protocol | Modbus RTU Protocol |
| Contact Capacity | DC28V/5A (Default State: Normally Open) |
| Measurement Accuracy | ±0.03 m or ±0.5% FS (Whichever Is Greater) |
| Repeatability Accuracy | ±0.25% FS |
| Resolution | 0.001 m |
| Characteristics | |
| Operating Temperature | -20℃~+60 |
| Storage Temperature | -40℃~+80 |
| Protection Rating | IP68 |
| Connection Method | Six-Core Cable, 2 m |
| Housing Material | ABS |
| Weight | 370 g |
