6 Split-Type Ultrasonic Sludge Level Meters Shipped to Shijiazhuang Qiaoxi Wastewater Treatment Plant

Ultrasonic sludge level meter is used in the sedimentation tank of a wastewater treatment plant to measure the amount of sludge accumulated. When it reaches a certain level, the sludge needs to be discharged on site. After sludge settles in the sedimentation tank, a phenomenon occurs where the bottom is sludge, the top is turbid water, and the middle is an emulsified layer. The signal reflection from the emulsified layer and the turbid water layer is very similar, which can cause significant measurement deviations—up to 3 to 5%.

Note: http://image0.chunsuns.com/site501/upload/album/20150624/2015062411174526866837.jpg

Figure 1: Physical view of the split-type ultrasonic sludge level meter

For this order, the customer required all ultrasonic sludge level meters to be equipped with stainless steel probes for measurement. Let's see how they are installed on site:

Note: http://image0.chunsuns.com/site501/upload/album/20150624/2015062411183805699174.jpg

Figure 2: On-site installation of the split-type ultrasonic sludge level meter

Fuzhou Dayu Electronics Technology Co., Ltd. has been manufacturing ultrasonic sludge level meters since 2008. They are mainly used in sedimentation tanks of wastewater treatment plants, thickeners in ore beneficiation plants, and sedimentation tanks in coal washing plants.

Source: Sales Department, Fuzhou Dayu Electronics Technology Co., Ltd.
